TK-IAH161 ANALOG INPUT MODULE NEW Honeywell REDUNDANT NET INTERFACE

Ironman Technology Co.,LTD

About us:

We specializes in automation parts and industrial controls, PLCS,DCS,Module/Board,Power supply,Controller, etc.We maintains an inventory of new and obsolete parts utilized in all areas of the manufacturing and industrial sectors.

Featured Brand:
● HONEYWELL ● AB ● OMRON ●SIEMENS ●SCHNEIDER

● ROSEMOUNT● ABB ● NOTIFIER ●MTL ● GE ●And many more !

TK-IAH161 ANALOG INPUT MODULE NEW Honeywell REDUNDANT NET INTERFACE

Lead time:3-5 days

New with one year warranty

Experion provides three I/O families that can be used in conjunction with the C200E/C200 control processor. The table below lists each family along with major characteristics.

Chassis Input/Output Modules-Series A (CIOM-A) is a chassis based platform. Modules exist in a single-wide and double-wide form factor. Modules are inserted into chassis slot positions; single-wide occupy one slot position while double-wide modules occupy two slots. As a platform, the chassis is host to not only I/O modules, but modules that perform other functions. Some examples include:  C200E Control Processor  Redundancy Module (RM)  Battery Extension Module  ControlNet Interface Module (CNI)  Ethernet Module

The I/O modules are the focus of this document. Other module types are covered in separate Specification documents. Figure 2-1 Experion Chassis Series Power Module power is supplied by a Series-A specific power supply. Power suppliers are available in a redundant and nonredundant configuration. The power module plugs to the left side of each chassis and does not consume a chassis slot position. The power supply provides DC power for the modules inserted into the chassis. Field power is provided by separate (external) power supplies. Series-A Chassis Types Chassis differ by the number of module positions or slots that the given chasses can accommodate. Chassis come in five versions (4, 7, 10, 13, and 17 slot). Some modules are double-wide and will use two chassis positions. Model Number Conventions (TC and TK) All model numbers are preceded by a TC- or a TK-. The TC designator indicates that the module is not conformal coated while the TK designator indicates that the module has conformal coating applied. Aside from this the modules are identical. Supported Control Processors All CIOM-A I/O modules are usable with the C200E control processor.

tc iah161

mc paih03

TK-IAH161 ANALOG INPUT MODULE NEW Honeywell REDUNDANT NET INTERFACE Images
